1.内胆为高级不锈钢板制成，外壳为SUS304＃不锈钢油发纹板。
2.动态旋转样品架，转速可调。
3.进口可编程控仪表，小型进口时间编程器。
4.设有滤光观察窗，有害气体排风口。
5.双金属黑板温度计。
6.多种安全保护装置。 主要技术指标:
| 型式Model | XR-XD普通型Common type | XR-XD高端型High level type |
| 温度范围Temperature scope | RT+10（室温+100C）～63℃，试验黑板温度： 65℃±3℃RT+10(indoor temperature+10℃)～63 ℃s and experiment blackboard temperature: 65 ℃ ±3 ℃ | |
| 湿度范围Degree of humidity scope | 65±3℃ | |
| 降雨时间Rain time | 0～9999min,可调0~9999 mins, adjustable | |
| 降雨周期Rain a period | 0～240min,间隔（断）可调0~240 mins, the partition(break) is adjustable | |
| 波长范围Wave-length scope | 290nm～800nm | |
| 辐照强度The Fu shines on strength | 550W/m2 | |
| 氙灯功率及寿命The light power and life span | 6KW水冷型，寿命500H；3KW风冷型，1000H(国产)The 6 KW water cold type, life span 500 Hs;The 3 KW breeze cold type, 1000 Hs(domestic) | 4.5KW水冷型,寿命2000H;1.5KW风冷型,寿命2000H(进口)The 4.5 KW water cold type, the life span 2000 Hs;the 1.5 KW breeze cold type, the life span 2000 Hs(importing) |
| 内箱尺寸Inside box size | 950×950×850㎜ | 800×800×800㎜ |
| 内胆材料Inside Dan material | 国产SUS304不锈钢板Domestic SUS304 stainless steel plank | 进口SUS304不锈钢板importing SUS304 stainless steel plank |
| 外壳材料Outer shell material | 高级冷扎钢板喷粉处理The high class cold firm steel plate sprays a powder processing | |
| 样品架Sample | SUS304不锈钢材料,转速≤5r±2/minThe SUS304 stainless steel material turn soon the ≤ 5 r ± 2/min | 铝合金材料,转速≤5r±2/minAluminum metal alloy material, turn soon the ≤ 5 r ± 2/min |
| 试样与灯管距离Try kind and light takes care of distance | 480mm有效暴晒面积6500cm cm2The 480 mms effectively and suddenly and violently basks the area 6500 cm cm 2 | 375mm有效暴晒面积6500cm cm2The 375 mms effectively and suddenly and violently basks the area 6500 cm cm 2 |
| 控制仪Control an instrument | 可编程触摸屏控制界面（国产）The programmable touch holds control interface(domestic) | 可编程触摸屏控制界面（进口）The programmable touch holds control interface(import) |
| 观察窗Observe a window | 双层滤光观察窗The double layer filters a light observation a window | |
| 黑板温度计Blackboard thermometer | 单金属黑板温度计Single metals blackboard thermometer | 双金属黑板温度计/进口辐照度计Double metals blackboard thermometer/the import Fu shine on a degree to account |
| 内外过滤片Inside outside percolation slice | 国产Domestic | 美国进口The United States is importing |
| 电源Power supply | 380V 50HZ | |
| 符合标准The sign is up to standard | GB/T16422.4-1999 GB/T2423.24-1995 ASTM G 155-2005等The GBs/T2423.24-1995s of the GB/T16422.4-1999 ASTM G 155-2005 etc.s | |
