JLLJ-3型液压平面下料机

本机适用于皮革、塑胶、帆布、尼龙、纸板、真空成型、复合材料、泡棉、包装及各种合成材料一层或数层的成型下料。 1、压板上下运动的导向靠两侧导轨，导向效果较好，保证了上下工作面的平行度。 2、采用双手操作，保证了操作员工的安全。 3、机器配有工作拖板，便于操作工取出刀模和安全。 4、主轴和轴座间安装有自润滑轴承不用加油，没有磨损。 5、适用于宽幅，多层材料的下料。 It is suitable for ming and laying-off of leather ,plastic cement,canvas ,nylon ,paper board ,vacuum forming ,composite material,blister cotton ,package, and various kinds of synthetic materials in one layer or numerous layers. a.The guide for the hold-down plate moving up and down is near to the lead rails in two sides .The good guide effect ensures the parallelism of upper and lower working sides. b.The double-hand operation ensures the operators safety. c.The machine is equppied with dragging plate so that it is easy for operators to take out cutter mold and ensures the safety. d.The compound bearing installed between the headstock and bearing seat doesn need any lubrication .No wearing. e.Suitable for laying-off of wide and multi-layer materials. 技术参数 最大冲裁力 Maximum momentum 250kn 裁断行程 Cutting distance 100-10mm 裁断面积 Area of striking panel 1600×500mm 电机功率 Engine Power 2.2kw 机械尺寸 Size of machine 2150×700×1300mm 净重 Weight of machine 1700kg
