关键名词：水冷式工业冷水机、冷冻机、水冷式冻水机 、冰水机 13632998248彭有顺
人体工学面板，全自动化控制，配备精密电温控制器，可长期平稳运行。
采用高效传热换热器，冷量损失少，易回油，传热管不致发生冻裂等优点。
采用欧美进口高性能压缩机，高EER值，噪声低，运行稳。
Special Features:
For a long-term stable operation,panel for ergonomics and automatic control harnesses precision
thermoelectric controllers.
Thanks for the high effective heat exchanger,the loss of cooling capacity is minimized,it is easy for
oil drain and the heating pipe is prevented from frost crack.
Equiped with a powerful compressor imported from U.S.and
Europe.The compressor operates smoothly and quietly at high EER ＆#118alue.
| 1.水冷型工业冷水机技术参数表(一) | ||||||||||
| 参数 Parameter | 型号 | AC- 03W | AC- 05W | AC- 08W | AC- 10W | AC- 15W | AC- 20W | AC- 30W | AC- 40W | AC- 50W |
|
| KW | 9.59 | 15.91 | 24.85 | 31.83 | 50.14 | 67.14 | 99.19 | 129.06 | 153.91 |
|
| kczl/h | 8251 | 13690 | 21375 | 27370 | 43120 | 57748 | 85303 | 110984 | 132359 |
| 总输入功率 | KW | 2.8 | 4.3 | 6.8 | 8.4 | 13.1 | 17.3 | 25.6 | 33.1 | 42.5 |
| 电源 | 3N~380V/415V 50HZ/60HZ | |||||||||
| 制冷剂 | 充注量Fill (kg) | 1.7 | 2.8 | 2.2×2 | 2.8×2 | 4.2×2 | 5×2 | 7.5×2 | 10×2 | 12.5×2 |
| 压缩机 | 功率Motor (kw) | 2.25 | 3.75 | 3×2 | 3.75×2 | 5.5×2 | 7.5×2 | 11.3×2 | 15×2 | 18.8×2 |
| 冷却水 | 水量Flow (m3/h) | 2.06 | 3.42 | 5.34 | 6.85 | 10.78 | 14.44 | 21.32 | 27.74 | 33.09 |
|
| 水阻力P.D. (Kpa) | 28 | 34 | 38 | 34 | 28 | 38 | 36 | 35 | 42 |
| 冷冻水 | 水量Flow (m3/h) | 1.65 | 2.74 | 4.27 | 5.47 | 8.62 | 11.55 | 17.06 | 22.19 | 26.48 |
|
| 水箱Tank (m3) | 0.038 | 0.065 | 0.11 | 0.188 | 0.285 | 0.285 | 0.405 | 0.61 | 0.61 |
| 水泵 | 功率Motor (KW) | 0.55 | 0.55 | 0.75 | 1.5 | 1.5 | 2.2 | 3.75 | 3.75 | 3.75 |
|
| 扬程Raise (Kpa) | 200 | 200 | 200 | 205 | 205 | 220 | 240 | 240 | 240 |
| 外形尺寸 | 长Length (mm) | 860 | 860 | 960 | 1360 | 1460 | 1460 | 1680 | 2080 | 2080 |
|
| 宽Width (mm) | 550 | 550 | 600 | 600 | 800 | 800 | 950 | 1000 | 1000 |
|
| 高Height (mm) | 930 | 1250 | 1440 | 1440 | 1610 | 1610 | 1810 | 1860 | 1860 |
| 重量Weight | (kg) | 120 | 150 | 210 | 290 | 400 | 440 | 690 | 850 | 1000 |
